Wedge bonding is a process used to attach connection leads between electronic components and a printed circuit. It is one of the two most common processes for making these connections, the other being ball bonding. Wedge bonding uses a wedge tool to form stitches on both ends without the use of a ball for the first bond. The bonds are thin and wedge-shaped. This process can utilize both gold and aluminum wire but is more commonly done with aluminum wire at ambient temperature.
| Characteristics | Values |
|---|---|
| Definition | An automated process that's used to attach connection leads between electronic components and a printed circuit |
| Process | Utilizes a wedge tool to form the stitches on both ends, without the use of a ball for the first bond |
| Bond Shape | Thin and wedge-shaped |
| Wire Used | Aluminum or gold alloy wires |
| Bonding Techniques | Normal wedge bonding, orthogonal bonding, basic wedge bond, wedge bond with loop consistency |
| Advantages | Ability to make finer pitch applications, stronger connections, smaller bond "footprint", suitable for bonding closely spaced terminals, ability to use ribbon for electrical requirements |
| Disadvantages | Lower production speeds, restrictions in the range of angular flexibility between component and PCB bonds |
| Tools Used | Wedge bonding machine, wedge bonding tool, wedge bonding anvil blocks, clamps & bridges |
Explore related products
What You'll Learn
Wedge bonding vs ball bonding
Bonding wedges are used in the wire bonding process, which is a method of making electrical connections between a microchip and its packaging, or between other electrical components. Wire bonding is a common method of making electrical connections, and it involves using a thin wire, typically made of gold, copper, or aluminium, to connect two points.
There are two main types of wire bonding: wedge bonding and ball bonding. This is how they compare:
Wedge Bonding
Wedge bonding utilizes a wedge-shaped tool to form the stitches on both ends of the wire, without the use of a ball for the first bond. The bonds are thin and wedge-shaped. Wedge bonding can use either ribbon or round wire for bonding and is commonly used with aluminium wire at ambient temperature. The wedge bonding tool needs to be oriented in the direction of the bond, which allows it to rotate and bond from all angles. This makes it suitable for bonding assemblies with limited space. Wedge bonding is typically used for fine-pitch applications of 40 microns or less and is slower than ball bonding, producing 3-6 wires per second. It is also useful for low-temperature or no-heat applications and running stitch interconnects.
Ball Bonding
Ball bonding, on the other hand, is a faster process, producing 5-12+ wires per second. It uses gold, palladium-coated, or copper wires and is commonly used for BGA, QFP, SOP, and MCM hybrid packages. Ball bonding is associated with thermocompression (T/C) and thermosonic (T/S) joining methods, which utilize pressure and temperatures of about 150 degrees Celsius to create an intermetallic bond. In ball bonding, the wire clamp is positioned above the tool, and the wire feeds through the centre of the ceramic capillary tool. This process disturbs the top-surface metallization, which can be addressed by creating a safety bond or a stand-off-stitch.
In summary, wedge bonding and ball bonding are two common wire bonding techniques, each with its own advantages and applications. Wedge bonding offers the ability to bond from all angles and is suitable for fine-pitch and low-temperature applications, while ball bonding is faster and more suitable for certain package types. The choice between the two depends on the specific requirements of the application, such as the pitch size, temperature constraints, and package type.
